7 Mounting and removing the machine 7.1 Removing the machine
7.1.1 Connecting ISOBUS Terminal
Machine with ISOBUS Terminal
Attention! Worn away cables can cause short-circuits or other faults in the control system. – Make sure that there are no wear points or trapping points!
1
• If necessary, connect the cable (1) to the control system. 1 CLAAS Communicator
• Lay the cable in the cab. • Make sure that there are no wear points or trapping points!
• Connect the terminal plug to the terminal: – ISOBUS Terminal – see Operator's Manual of the terminal being used. – CLAAS Communicator – connect to the outer connection (2) (Fig. 2). 2
– Tighten the securing screws on the terminal plug.
• Fix the terminal to the bracket in the cab. 2
000 295 387 0 - Erg BA QUANTUM 6800 S / P
(Fig. 1, 2)
15
