5 Carry out before initial use 5.2 Assembling / adapting the machine
5.2.3 Connecting the silaging material unit The machine is prepared for operation with a silaging material unit. Mount the silaging material unit and connect to the 2 pole plug (S) “Auxiliary silaging material”.
S
Plug pin allocation: – Pin 1 = Power mass connection – Pin 2 = Signal – loading: max 3A 6 Power is applied to the “Auxiliary silaging material” plug if the following requirements are fulfilled: – Machine is in loading mode, – the pick-up has been lowered to the floating position and – the silaging material feed has been activated – see Switching on / off the silaging material feed, page 54. – Power is applied to the plug auxiliary silaging material in the wiring harness during loading. (Fig. 6)
