911 Carrera 911 Carrera S
2.6 Fuel system Fuel supply, low-pressure side The engine is designed to provide optimum performance and fuel consumption if premium unleaded fuel 93 octane (
R+M 2
DME engine electronics
) is used. The engine is suitable for operation
with fuel containing up to 10% ethanol. The use of fuels containing ethanol can
2
result in increased fuel consumption. If unleaded fuel with 90 octane ( R+M 2 ) or less is used, the engine’s knock control automatically adapts the ignition timing. The use of unleaded fuel with octane numbers of less than 90 octane ( R+M 2 ) could
at full throttle. Fig. 2_412_11 C2 fuel tank, 16.9 gal. (64 liters), 2.6 gal. (10-liter) reserve Carbon canister (not for USA) Installation position of the control unit for the electric fuel pump flow control under the battery retaining bracket.
cardiagn.com
reduce engine power and increase fuel consumption. The vehicle must not be driven
2_412_11
Special tool 9731 1 The special tool 9731 1 (Fig. 2_413_11) is used for opening the fuel tank cap on the top of the fuel tank (Fig. 2_414_11, 1).
Control unit for electric fuel pump
9731 1
The control unit for electric fuel pump flow control (Fig. 2_416_11, 2) is installed under the battery tray (3). Depending on the amount of fuel required, the current consumption on Carrera 2 vehicles, and thus the delivery rate of the electric fuel pump, is controlled at a level between 6 and 15 amps. The current consumption
2_413_11
can be measured at the fuse of the electric fuel pump.
2_416_11
2_414_11
