OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Floodlamps, driver’s cab
40001292.00-en
Floodlamps front/rear Floodlamps switch on, driver’s cab Switch 42 (Fig^. 2) Press the pushbutton with the symbol once, the symbol lights up – Front floodlamps ON Switch 42 (Fig. 2) Press the pushbutton with the symbol twice, the symbol lights up – Floodlamps front and rear ON Fig. 1
The floodlamps (arrows, Fig. 1) are activated and deactivated with switches (42, 43 + 44, Fig. 2).
Floodlamps switch off, driver’s cab Switch 42 (Fig. 2) Press the pushbutton without the symbol, the symbol does not Light up floodlamps OFF
Fig. 2
The floodlamps can only be used when the headlamps are on low beam or when the side-marker lamps are on.
Fig. 3
The floodlamps can only be used when the headlamps are on low beam or when the sidemarker lamps are on. Î
73
