OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Rotary beacon (option)
Press the lever (21, Fig. 16) and remove the cover (22).
40001358.00-en
Rotary beacon, replacing the reflector Remove the cover (22) as described above. Remove hook (24, Fig. 18) with the help of small pliers. The reflector and motor (25) can now be removed completely.
Fig. 16
Remove the lamp (23, Fig. 17) and replace with a new one. Fig. 18
Install a new reflector with motor (25). Refit hook (24) and put cover (22) back in place. Retrofitting a rotary beacon The rotary beacon is fixed with 4 screws (1, Fig. 19) at the rear of the cab roof on the right. The beacon is connected to the power supply by means of the prefabricated cable with connector (2, Fig. 19).
Fig. 17
Replace the cover (22). Press the lever (21) and snap on the cover (22) until it audibly engages.
Fig. 19
269
