OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Floodlamps (7, Fig. 1)
Fig. 13
Loosen screw (40, Fig. 13) and carefully remove headlamp insert (41) from the housing.
Fig. 14
Slide spring clamp (42, Fig. 14) in the direction of the arrow and fold it up.
Fig. 15
Remove bulb (43, Fig. 15) from headlamp insert (41) and replace with a new one. Slide the bulb into the headlamp insert (41) and engage the spring clamp in headlamp insert (41). Place the headlamp insert (41) back on the housing and fasten with the screws.
267
