OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Engine fault codes Code
40001343.00-en
Meaning
Possible repair steps
3000
white
Unknown fault code (DTC + FMI)
No action required
3000
yellow
Unknown fault code (DTC + FMI)
Follow the instructions on the display, contact CNH Service
3000
red
Unknown fault code (DTC + FMI)
Switch off engine, follow the instructions on the display, contact CNH Service
3001
red
Accelerator sensor – signal not plausible
Idle speed switch faulty or idle speed switch cable broken or accelerator pedal faulty. Check wiring, replace idle speed switch or accelerator pedal.
3002
red
Accelerator sensor – signal exceeds upper tolerance
Short circuit in wiring or in accelerator. Check wiring or replace accelerator pedal.
3003
red
Accelerator sensor – does not reach lower tolerance
Short circuit in wiring or in accelerator. Check wiring or replace accelerator pedal.
3004
red
Accelerator sensor – no signal
Check wiring or replace accelerator pedal.
3006
yellow
Coolant temperature sensor – signal not plausible
See plausibility check for oil temperature sensor (fault code 3033).
3007
yellow
Coolant temperature sensor – signal exceeds upper tolerance
Sensor faulty or short circuit to external source. Check wiring or replace sensor.
3008
yellow
Coolant temperature sensor – signal below lower tolerance limit
Sensor faulty or short circuit to external source. Check wiring or replace sensor.
3009
yellow
Coolant temperature sensor – no signal on CAN
CAN plausibility check not carried out. Restart system if malfunction occurs again. Check wiring or replace sensor.
3010
yellow
Intake air temperature sensor – signal exceeds upper tolerance limit
Sensor faulty or short circuit to external source. Check wiring or replace sensor.
3011
yellow
Intake air temperature sensor – signal below lower tolerance limit
Sensor faulty or short circuit to external source. Check wiring or replace sensor.
3012
yellow
Intake air temperature sensor – no signal on CAN
CAN plausibility check not carried out. Restart system if malfunction occurs again. Check wiring or replace sensor.
3013
yellow
Main relay 1 (high-pressure pump) – short circuit to battery (+).
Check the main relay and wiring.
3014
yellow
Preglow system/battery main switch relay – short circuit to ground
Check the relay and wiring.
3015
yellow
Fuel temperature sensor – signal exceeds upper tolerance
Sensor faulty or short circuit to external source. Check wiring or replace sensor.
3016
yellow
Fuel temperature sensor – signal exceeds lower tolerance
Sensor faulty or short circuit to external source. Check wiring or replace sensor.
136
