OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Combination instrument configuration menu
40001353.00-en
The change model screen (1) can be selected in the configuration screen (1, Fig. 2) and called up with the ENTER key (Fig. 3).
Fig. 1
The configuration screen (7) can be selected by scrolling and called up by using ENTER (7, Fig. 1).
Fig. 3
Change model message 1
Change model
2
Confirmation
Pressing the ENTER key activates the model selection screen (Fig. 4)
Fig. 2
Configuration 1
Change model
2
Tire selection
3
Transmission calibration
4
Fan test
5
Special screen
Fig. 4
The respective model is selected with the arrow keys and the selection confirmed with the ENTER key. After selecting the model in screen (Fig. 4), the following screen (Fig. 5) is displayed.
130
