OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Rear ripper (option)
Read and observe: “Working operation, safety instructions”.
40001308.00-en
• Withdraw the cotter pins (4, Fig. 2) and remove retaining pin (3).
The rear ripper is equipped with up to five ripper teeth and can be used for heavy-duty ripping work. Use the ripping teeth only in symmetrical arrangement.
Before lowering the rear ripper, set the ballcock (4, Fig. 5) to position A.
Rear ripper, working position • Tilt teeth protection (2, Fig. 1) backwards (Fig. 2). It is held in this position by springs.
Fig. 2
• Move a tooth into working position (5, Fig. 2) and fasten with retaining pin (3). Secure the retaining bolt with cotter pin (4) and safety ring (6).
Fig. 3 Fig. 1
110
