OPERATING INSTRUCTIONS Brake-pressure-dependent transmission cutout/Inching (option)
F106.7/F106.7A/F156.7/F156.7A
40001302.00-en
The grader can be equipped with a brakepressure-dependent transmission cutout function which is activated at a brake pressure of 25 bars. This function can be switched on and off. The brake-pressure-dependent transmission cutout is activated only in 1st, 2nd and 3rd forward gear and in 1st reverse gear. The brake-pressure-dependent transmission cutout is switched on with rocker switch (86, Fig. 1).
Fig. 1
Press the pushbutton with the symbol • The symbol is lit up – brake-pressure-dependent transmission cutout ON Press the pushbutton without the symbol. • The symbol does not light up – brake-pressuredependent transmission cutout OFF
92
