OPERATING INSTRUCTIONS
F106.7/F106.7A/F156.7/F156.7A
Driving
40001299.00-en
Read and observe the chapter “Driving, safety instructions”.
Driving on public roads For driving on public roads, the specific road traffic regulations applicable in the country of use must be observed. Our service department will be pleased to answer any queries in this respect.
• Bring the blade into the driving position (Fig. 2) such that the blade does not protrude over the dotted line. For the purpose of easier adjustment, marking lines (1, Fig. 2) have been put on the slewing ring and on the blade. • For driving on public roads, the brake-pressuredependent gearbox cutout function must be off (see section “Brake-pressure-dependent gearbox cutout function”).
Take the following steps before driving on public roads: • Clean the machine to remove dirt. • Lock the articulated joint. • Check the brakes, steering, tyres and the lighting system. • Switch off the floodlamps. • Lower the splash-guards on the front wheels (Fig. 1).
Fig. 1
Fig. 2
• Check the wheel lean hydraulic cylinder for proper operation. For checking, move the control lever (72, Fig. 3) several times from limit stop to limit stop.
Fig. 3
Î
85
