6.1.10 Elevation lower limit As for the cranes whose moment detection is the differential pressure detection type, the moment detection becomes no longer possible when the elevating stroke end is reached. This function stops the elevation before the lowering stroke end is reached. However, to achieve the traveling configuration, when the slewing angle and boom length condition are satisfied, the lowering can be performed to the stroke end without a stop. Stop condition: Boom angle ≤ Boom lowering stop angle A°. GR-130N-1
GR-160N-3
GR-250N-3 GR-700N-1
-1.7
-5.3
-
Angle A°
Cancel: 100% stop cancel Code at stop: W0054 “Stopped by elevating cylinder stroke end” Stop operation: (×: Stop operation) Main winch
Aux. winch
Boom telescoping
Boom elevation
Jib telescoping
Up
Up
Ext.
Rse.
Ext.
Down
Down
Ret.
Lwr.
Ret.
Jib tilt Rse.
×
