6.1.7 Load radius limit stop Restriction is implemented to the operations exceeding the load radius that is set with the area limit. Code at stop: W0029 “Stopped at lifting height limit restriction” Cancel: 100% stop cancel (Di6: ON) Stop operation: (×: Stop operation) Main winch
Aux. winch
Boom telescoping
Boom elevation
Jib telescoping
Up
Up
Ext.
Rse.
Lwr.
Ext.
×
×
Down
Down
Ret.
×
Ret.
Jib tilt Rse.
Lwr.
Slewing Right
Left
Jib mounting Ext.
Stw.
×
6.1.8 Automatic stop by unlock the jib fixing pin When the power tilt jib is stowed, in order to protect the support, the tilt lowering operation is stopped in the case of side up jib, and the tilt raising operation is stopped in the case of midair extension jib. For the side up jib, tilt lowering operation and jib extending operation are stopped in order to prevent the tension rod from buckling while the jib is being stowed. For the midair extension jib, tilt raising operation and jib extending operation are stopped for the purpose of support protection. Stop condition: (1) Jib connecting (lock) pin detection is in "inserted" status (Di7: ON). (2) Jib lock (automatic) pin detection is in "inserted" status (Di4: ON). Status that either of the above conditions (1) or (2) is met. Code at stop: W0044 “Jib stowed condition” Stop function cancel: None Stop operation: (×: Stop operation) M winch Up
Down
A winch Up
Down
Boom telescoping
Boom elevation
Jib telescoping
Ext.
Rse.
Ext.
Ret.
Lwr.
Ret.
Jib tilt Rse.
×
×
× ×
Lwr.
×
Slewing Right
Left
Jib mounting Ext.
Jib type
Stw.
×
Side up jib
×
×
Midair extension jib
×
×
Midair extension jib
With the midair extension jib (SACO jib), when the jib telescoping is selected without the jib connected.
