4.6.8 Activate/deactivate boom elevation slow stop function
NOTICE If the boom elevation slow stop function is deactivated, automatic stop can cause the load slewed and it can damage the machine. Slowly operate the boom elevation. To decrease the load sway, this function decreases the boom elevating speed when the boom elevation operation stops. Select the elevation slow stop activated or the elevation slow stop deactivated.
1. Select the activate/deactivate elevation slow stop function icon and press the set key. • The pop-up window for the icon appears on the display panel. 2. Press the <
> key (backward) or the <
> key
(forward) to select the icon. • The selected icon is highlighted.
3. Press the <
> key (set).
• After the registration is completed, the pop-up window closes and the AML returns to the initial display. • When the elevation slow stop canceled is registered, the icon for the elevation slow stop canceled appears. When you stop registration, press the cancel key. The pop-up window closes and the AML returns to the initial display without completing the registration. Even after you turn off the AML, the registered information is retained. When the AML is turned on, the operation starts with the retained information.
