User Mode
Cha pte r B
Cha pte r B
4.6.7 History indication of fuel consumption The fuel consumption history is displayed. 1. Lower the load and set each control lever and pedal to the neutral position. 2. Select the fuel consumption history icon, and then press the <
> key (set).
• The screen for fuel consumption history appears. (ex.: GR-700N-1)
3. The display changes when the <
> key (display
change) is pressed. • The fuel consumption history is shown in either a barograph or number. • The items shown on the numeric display screen are as follows. L(N):
Fuel consumption during standby (liter)
L(D):
Fuel consumption during crane operation (liter)
min/L: Fuel consumption ratio during crane operation (minute/liter). You can change the unit of fuel consumption ratio in min/L (minute/ liter) or L/h (liter/hour) by pressing F2 (unit change) key. tm:
Crane operation amount (hook load (ton) × load travel amount (meter))
The measurements restart when < > key (reset) is pressed. The previous records are moved down by pressing < > key (reset). 6 previous records including the current rate are displayed. You can reset the histories both for traveling and crane operation at the same time by pressing < > key (reset) and hold it for a while. Press <
> key (cancel) to exit the history display.
The pop-up window closes and the AML returns to the crane operation state. The load travel amount is the traveled distance in vertical, horizontal, and back and forth directions. The fuel consumptions of L (N) and L (D) include those during on-rubber (creep) operation. The value of k in tm is indicated as k × 1,000. If the value exceeds the maximum value (9999k) of the applicable number of digits (4-digit), all histories are reset.
B - 37
W301-0481E
