Cha pte r B 4.6.3 Selection of Eco mode
Select a crane operation mode when Eco mode switch is "ON". • Eco mode 1: In this mode, a crane restricts the maximum engine speed, consumes less fuel and makes less noise compared with when ECO mode is "OFF". • Eco mode 2: In this mode, a crane consumes further less fuel and makes further less noise compared with when ECO mode 1 is selected. A crane operation becomes slower by restricting the maximum engine speed. Select a suitable ECO mode depending on crane operation. 1. Select the Eco mode selector icon, and then press the <
> key (set).
• The pop-up window for Eco mode selection appears on the display panel. 2. Press the < > key (backward) or < > key (forward) to select one of the Eco mode icons. • The selected icon is highlighted. 3. Press the <
> key (set).
• After the registration is completed, the pop-up window closes and the AML returns to the crane operation state. • When ECO mode switch is turned "ON", ECO mode indicator (ECO mode 1 or ECO mode 2) is displayed. When you stop registration, press the <
>
key (cancel). The pop-up window closes and the AML returns to the initial display without completing the registration. Even after you turn off the AML, the registered information is retained. When the AML is turned on, the operation starts with the retained information.
