4.3 Fuel consumption indication function CAUTION When you check the fuel consumption indicator, be careful so that crane operation is not hindered. Distraction can cause a serious accident. This function shows the fuel consumption during a crane operation or standby. Checking the indication enables you to operate a crane in an environmentally friendly way. The fuel consumption is displayed when the PTO is "ON", the following items are shown. The fuel consumption includes those during on-rubber (creep) operation. 1. Current fuel consumption The current fuel consumption (min/L) during crane operation is shown as a barograph. The minimum and the maximum value in a bar graph is following table. GR 130N-1
160N-3
250N-3
700N-1
Min. value
4.0
2.0
1.0
1.0
Max. value
14.0
12.0
11.0
11.0
2. Average fuel consumption The average fuel consumption (min/L) during a crane operation is shown. The average fuel consumption is reset during standby or when PTO switch is turned to "OFF". 3. Fuel consumption during standby The fuel consumption (L) during standby is shown. 4. Standby period The crane standby period (min) is shown. The crane standby period is the period when each control lever and pedal are in neutral position. The fuel consumption during standby and the standby period are displayed when a crane has been in standby mode for a specified period. The displayed data may be different from the actual data depending on work conditions. Check the fuel gauge to see the remaining fuel amount. The fuel consumption history during a crane operation and standby. Refer to ”4.6 Preset Menu”.
