User Mode
Cha pte r B
Cha pte r B
B-4 Other Functions There are other 7 functions as shown below. No.
Functions
1 2 3 4 5 6 -1 -2 -3
Working range limit function TARE function Fuel consumption indication function Mute alarm function Selection of over-front special capacity Preset menu – Selection of Eco mode – Boom elevation speed adjustment – Initialization of hook block position – Activating/deactivating the winch drum rotation buzzer function – History indication of fuel consumption – Activate/deactivate boom elevation slow stop function – Adjustment of hook block travel amount – Adjustment of display panel contrast – Maintenance telescoping mode – Telescoping correction function – Telematics data transmission Back light lit (unlit) function
-4 -5 -6 -7 -8 -9 -10 -11 7
130N-1
GR160N-3 250N-3
–
–
–
–
–
–
–
–
–
–
4.1 Working range limit function NOTICE If the work range limit is registered close to an obstacle, the machine can hit the obstacle depending on the crane configuration and operation methods. Consider a sufficient allowance when you register the limit. The work range limit function restricts the operation of the crane to the pre-registered boom angle (upper limit, lower limit), lifting height, load radius, and slewing angle (left, right). Use this function when operating the machine in a place where there are obstacles around the machine or when requiring the working range limit of the boom. When the crane reaches the registered working range, the limit function activates as follows: Working range limit function Boom angle upper limit Boom angle lower limit Lifting height limit Load radius limit Left slewing limit Right slewing limit
Action • Crane stops automatically. • AML built-in buzzer
B - 20
W301-0481E
700N-1
