Cha pte r A CN5 connector Pin No.
Cha pte r A
Components of AML System Signal names and functions
Name
- Signal name: External indicator lamp (up to 90%, green) When the moment load factor is less than 90%, the green external indicator lamp lights. Output condition: (1), (2) and (3) (1): Moment load ratio is less than 90%. (2): 100% stop cancel indication (Di6) is "Not canceled" status. (3): Anti-two-block cancel indication (Di5) is "Not canceled" status.
14
Do14-
When in the boom operation with jib elected (during main operation with jib elected), the green external indicator lamp lights when the moment load ratio described below is reached.
Outrigger extension width
Output GR-130N-1, 160N-3
Maximum extension Middle extension 3
Less than 80%
Middle extension 2 Middle extension 1
GR-250N-3
GR-700N-1
Less than 78%
Less than 75%
Less than 73%
Less than 70%
Less than 68%
Less than 65%
Output when condition is met: OFF output - Signal name: External indicator lamp (90% to 100%, yellow) When the moment load factor is 90% or more and less than 100%, the yellow external indicator lamp lights. Output condition: (1), (2) and (3) (1): Moment load ratio is 90% or more and 100% or less. (2) 100% stop cancel indication (Di6) is "Not canceled" status. (3): Anti-two-block cancel indication (Di5) is "Not canceled" status.
15
Do15-
When in the boom operation with jib elected (during main operation with jib elected), the yellow external indicator lamp lights when the moment load ratio described below is reached.
Outrigger extension width
Output GR-130N-1, 160N-3
Maximum extension Middle extension 3 Middle extension 2
80% or more Less than 90%
Middle extension 1
Output when condition is met: OFF output
A - 21
W301-0481E
GR-250N-3
GR-700N-1
78% or more Less than 88%
75% or more Less than 85%
73% or more Less than 83%
70% or more Less than 80%
68% or more Less than 78%
65% or more Less than 75%
