Adjustment mode
- Fully retract the jib tilt cylinder, then press the <
Cha pte r D
> key to store the jib offset angle to machine A/D input
value (Fig. 6.1.5). When the jib tilt full retraction position is stored, " " is shown at the left of jib tilt full retraction memory A/D data. When the <
> key is pressed, the data will not be stored, and the screen returns to the adjustment main
menu of Fig. 1.3.3.
Fig. 6.1.5 Jib tilt full retraction position storing completion screen Under the status shown in Fig. 6.1.5, pressing the <
> key returns the screen to the adjustment main menu of
Fig. 1.3.3.
