Cha pte r D
Adjustment mode
Cha pte r D
2.5 Outrigger Length Adjustment The outrigger adjustment can be performed with four outriggers at the same time, or separately with each outrigger.
2.5.1 Outrigger Length Zero Adjustment 1. Fully retract all four outrigger beams. 2. Until "RFront O/R" and "Zero adjustment value" become highlighted on the LCD (Fig. 2.1.1), press the < > key (backward) or the < > key (forward).
RFront O/R [m]
Value
ZERO
SPAN
1.281
1.275
3.600
Detected Right Front outrigger length
Zero adjustment value
3. Operate the < > key (-) and the < > key (+) so that the detected Right Front outrigger length becomes the zero adjustment value. When the adjustment length is reached, press the <
> key to register the
adjustment value. After the adjustment value is registered, " " is shown at the left of zero adjustment value. 4. Also for the outrigger length of Left Front, Right Rear, and Left Rear, operate the < > key (backward) and the < > key (forward) to show the zero adjustment display, and then perform the adjustment and registration.
Display of Left Front outrigger zero adjustment Value
ZERO
SPAN
LFront O/R [m] 1.281
1.275
3.600
Display of Right Rear outrigger zero adjustment RRear O/R [m]
Value
ZERO
SPAN
1.281
1.275
3.600
Display of Left Rear outrigger zero adjustment LRear O/R [m]
Value
ZERO
SPAN
1.281
1.275
3.600
D - 14
W301-0481E
