Cha pte r D
Adjustment mode
Cha pte r D
1.3.3 Shift to Adjustment Mode To shift to the adjustment mode, select “2. Adjust” in the maintenance main menu of Fig. 1.3.1. At this time, the LCD shows a screen as shown in Fig. 1.3.2, and the screen waits for the ID code input. Once the ID code (Note 1) is input correctly, the shift is made to the adjustment mode, and the LCD shows the adjustment main menu shown in Fig. 1.3.3. If the ID code is incorrect, the pressing of <
> is disabled.
Until the operation history is erased for three times, the ID code input screen is not displayed, shift to the adjustment main menu of Fig. 1.3.3 (Note 2).
Fig. 1.3.2 ID code input display Input the ID code (6 digits) according to the steps below. A numerical value is displayed only for the digit that is being input. A character " " is shown in other digits. Move the digit to input using the < > key (backward) and the < > key (forward). In the digit that is being input, press the < > key (-) or the < > key (+) to decrease / increase the value. Press the <
> key to confirm the input value.
Note 1: ID code is changed daily based on the date. (If you need the ID code, contact to Tadano Overseas Div. in Tokyo) Adjustments of calendar and clock must be done in advance before inputting the ID code. Note 2: After a replacement of AML related part or CPU board, erase the operation history for three times so that the ID code input screen is displayed.
D-5
W301-0481E
