Cha pte r C
Maintenance Mode
Cha pte r C
C-2 Individual Main Menu Functions 2.1 ROM ID check In the maintenance main menu of Fig. 1.3.1, select "ID Code Check," and press the < > key to display the AML ID check screen shown in Fig. 2.1.1. Pressing the < > key quits the menu, and the display returns to the maintenance main menu. Displayed items are listed below. When the transmitter STM-D is connected, pressing the < > key or the < > key displays the connected device ID check screen shown in Fig. 2.1.2. - ROM Code No. - Crane Spec (Crane Specification code) - Data ID - Program ID - Making date of data. (From left, year, month, day.) - DCU2 Code No. - VCU Code No. - VCU Sub Rev.
(The items differ depending on the model.)
Fig. 2.1.1 AML ID check screen
(The items differ depending on the model.)
Fig. 2.1.2 Connected device ID check screen
C-6
W301-0481E
