9.6 User preset menu When performing the maintenance operation including grease-up for boom, press the preset menu key and select the user preset menu in the user preset menu screen (Fig. 9.6.1) with F3 or F4 key.. Press the set key, the adjustment screen for the selected icon is displayed (Fig. 9.6.2).
Fig. 9.6.1 User preset menu selection In the user preset menu, a switch is made to the special capacity (only hook plus alpha) for the maintenance. Also, only the boom full retraction detect switch abnormality error will not be detected. Lifting performance when user preset menu has been selected, shall be handled as one of the special telescoping (referred to as the user telescoping). During the user preset menu, the boom is explicitly indicated by coloring as shown in Fig. 9.6.2.
Fig. 9.6.2 Adjustment screen
