RAYMOND SERVICE INFORMATION
The Raymond Corporation Corporate Headquarters P O Box 130 Greene, New York 13778-0130
RSI CTB-15-005
Model
September 10, 2015
4700
SUBJECT:
Power Amp Drip Guard
GENERAL INFORMATION:
A Drip Guard is available for trucks with battery rollers to prevent battery acid from dripping on the power amplifier. Refer to the following table when ordering parts.
SERVICE INFORMATION:
Remove existing hardware in battery compartment per Figure 1. Install the drip guard per Figure 2 using the hardware listed below. Apply thread-locking compound P/N 1013829 and torque to 21 ft. lb. (29 Nm). Item
Description
1
Drip Guard
2 3 4
Screw Nut Washer
Models C30, C40, C50HM C50, C50HP, C50L, C60 All
Part Number 1214824/001 1214824/002 5-004-022 5-016-005 5-018-006
Qty. 1 1 2 2 2
Remove existing hardware
See Figure 2
Figure 1. Right Side Electrical Compartment ®
Raymond is a registered trademark of The Raymond Corporation 2015 The Raymond Corporation. FOTP-0060/1-7-15/F
RSI CTB-15-005 Page 1 of 2
