RAYMOND SERVICE INFORMATION
The Raymond Corporation Corporate Headquarters P O Box 130 Greene, New York 13778-0130
RSI CTB-16-001
Models
May 25, 2016
4450, 4700
SUBJECT:
New Vehicle Managers and Software Available
GENERAL INFORMATION:
New Vehicle Managers are available for Models 4450 and 4700. These new Vehicle Managers require new versions of software. Refer to the following table. Model 4450 4700
SERVICE INFORMATION:
VM Part Number 2773117CE 2943037CE
VM S/W Version 8.2 9.0
Order and install the new Vehicle Managers as required. Notes: • *Model 4450: VM P/N 2773106CE requires S/W Version 6.0 or lower. • *Model 4700: VM P/N 2773063CE requires S/W Version 6.3 or lower. *If a higher version of software is installed in an old P/N Vehicle Manager, an F code is displayed, even though the circuits are OK. Codes C1, C2, C4, and C8 have been changed to Codes F1, F2, F4, and F8 in the new software. The F Codes indicate a short circuit.
PARTS AVAILABILITY:
Now available through the Raymond Portal.
FILING INSTRUCTIONS:
File this notice in Maintenance Manuals: • 1113065B next to pages iv, 6-23, and 6-28 (Model 4450) • 1116093A next to pages iv, 6-26, and 6-31 (Model 4700)
®
Raymond is a registered trademark of The Raymond Corporation 2016 The Raymond Corporation. FOTP-0060/1-7-16/G
RSI CTB-16-001 Page 1 of 1
