Model 4700 Maintenance Manual Mast Figure 7-93.
Section 7. Component Procedures Fork Carriage with Sideshift - TF/TT Mast
Carriage Frame Removal
4. Apply thread-locking compound to the four socket head cap screws. Secure the side plate to the carriage. See Figure 7-95. Figure 7-95.
NOTE: The lower carriage shims and slider may fall out when the carriage is pulled to the side. The carriage shims and slider are installed between the lower sideshift ram housing and the carriage frame.
Installation 1. Attach a safety strap to the middle of the carriage frame. 2. Suspend the carriage frame beside the sideshift mechanism. NOTE: Confirm that all shims and sliders are in position as the sideshift frame is installed.
Side Plate Mounting Bolts
5. Slowly sideshift in both directions to make sure the rams are touching both sides of the frame. 6. Maximum sideshift in both directions to check that there is no binding or excessive play, and that the carriage moves smoothly in both directions. 7. Install the forks on the sideshift carriage. 8. Install the load backrest, if present.
3. Carefully slide the carriage frame onto the sideshift mechanism. Remove the strap when it begins to interfere with reinstalling the carriage frame. See Figure 7-94. Figure 7-94.
Carriage Frame Installation
Publication 1160093, Issued: 20 May 2013
7-75
