519 Telehandler
ELECTRICAL
STEERING MODE CIRCUIT TESTS STEP 33
2 1
G1007060
G1007040
Test for power to the fuse #2 (1) and the ignition relay (2) and check fuse #2 (1).
Install the positive (+) test lead in the orange/white prong of the wire harness. With the key switch in the ON position and the steer mode switch in the crab steer position, the multimeter should read 12 to 13 volts. If there is no voltage, proceed to Step 35.
STEP 34
G1007059
Set the multimeter to read DC volts. Disconnect the 4-wheel steer wire harness (green and black wires) from the steer mode solenoid connector located under the front cover.
913302
G1007059
If there is 12 to 13 volts, but the 4-wheel steer mode does not function, replace the solenoid valve. Connect the wire harness to the 4-wheel steer mode solenoid connector.
301-20
