519 Telehandler
ELECTRICAL
PARK BRAKE CIRCUIT TESTS
STEP 24
STEP 22
1 2
G1007045
G1007057
Check the park brake fuse (#2) (1) and test for power to the fuse, refer to (Step 4). Check the ignition relay power (2), refer to (Steps 5 and 6). If there is 12 to 13 volts at the park brake fuse, proceed to the next step.
Connect the positive (+) test lead to the bottom terminal (#2) of the relay socket (relay terminal 85). With the key switch and park brake switch in the ON position, the multimeter should read 12 to 13 volts. If there is no voltage, proceed to Step 30. If there is 12 to 13 volts, proceed to the next step.
STEP 25 STEP 23
G1007036 G1007044
Remove the park brake relay. Connect the positive (+) test lead to the right side terminal (#3) of the park brake relay socket (relay terminal 30). Turn the key switch to the ON position.
Move the park brake switch to the OFF position. The multimeter should read 0 volts. If there is no voltage, proceed to the next step. If there is 12 to 13 volts, proceed to Step 28.
If there is no voltage, repair or replace the wiring between the fuse and the relay. If there is 12 to 13 volts, proceed to the next step.
