519 Telehandler
ENGINE
STEP 18
STEP 21
G1107079
G1107052
With the help of an assistant, remove the three side mounting bolts from the radiator bracket and remove the radiator.
Remove the two air filter bracket mounting bolts an remove the air filter assembly.
STEP 22
STEP 19
1
2
2
1
G0208007
Loosen the hose clamp (1) and remove the upper air intake hose (2).
Loosen the hydraulic oil fill cap (1) to relieve residual pressure in the system. Remove the hydraulic hose (2) from the oil cooler. Install a cap and plug on the fittings.
STEP 20
STEP 23
G1107049
1
1
2 1
G1107051
G020809
Loosen the hose clamp (1) and remove the lower intake hose (2).
913302
Disconnect the tube (1) from the oil filter. Cap and plug the fittings. Disconnect the hydraulic tank breather line (2).
