519 Telehandler
INNER BOOM
STEP 26
STEP 28
G1007113
G1007073
Raise the boom enough to access the tilt cylinder and auxiliary hydraulic line connectors. Remove the caps and plugs from the hydraulic connectors. Connect the hydraulic lines and tighten.
Remove the caps and plugs from the extend cylinder hydraulic lines. Install the hydraulic lines to the extend cylinder. NOTE: Do not tighten.
STEP 27
STEP 29 1 1 2 2
G1007102
With the main boom lowered and the inner boom fully retracted from the back of the machine, install the top left wear pad and bolts. Tighten the bolts.
913302
G1007074
Install the hydraulic lines mounting block and tighten the nuts (1). Connect the hydraulic hoses (2) and tighten.
