519 Telehandler
INNER BOOM
STEP 8
STEP 10 2
2
1
1 G1007113
G1007086
Raise the main boom to access the tilt cylinder and auxiliary hydraulic line fittings. Relieve the hydraulic pressure from the lines. Disconnect the hydraulic fittings. Cap and plug all fittings.
Disconnect the front lights wiring harness connectors (1). Remove the two mounting bolts (2) from the light bar. Remove the lights.
STEP 11
STEP 9 2
1
G1007095
Mark all inner boom wear pads for reassembly.
G1007108
Lower the boom onto the support stand (1). Using a chain hoist and lifting strap apply upward pressure on the front of the inner boom (2).
NOTE: Some pads may have shims.
STEP 12
G1007096
Remove the six top wear pad retaining bolts. 913302
