519 Telehandler
LIFT CYLINDER
STEP 6
STEP 9
G0907010
G0907005
Using the chain hoist and lifting strap, position the lift cylinder in the cylinder mount.
Remove the chain hoist and lifting strap.
STEP 10
STEP 7
Start the engine. Move the machine to an open area and park on a level surface. Apply the parking brake. Raise and lower the boom several times until all air is removed from the circuit.
STEP 11 Lower the boom and shut off the engine. Check for leaks. Correct any leakage found. Check the hydraulic fluid level. If necessary, fill to the correct level with the specified fluid.
G0907009
Install the upper pivot pin.
STEP 8
G0907008
Install the snap ring on both sides of the upper pivot pin.
