519 Telehandler
CYLINDER REPAIR
STEP 6
STEP 9
G0907036
G0907033
Install a new wiper ring and O-ring in the head gland.
Install the O-ring on the cylinder rod.
Apply a thin coat of oil on the seal, wear ring and wiper in the head gland, prior to installation on the rod.
Push the O-ring against the base. Be sure the O-ring is not twisted.
STEP 10
STEP 7
G0907032
Install the piston on the cylinder rod.
G0907035
Using care, slide the head gland over the threads and onto the cylinder rod.
STEP 11
STEP 8 3
2
1
G0907031
Apply Loctite® #271 Thread Lock (or equivalent) on the threads. Install and tighten the nut on the cylinder rod to 450 ft.- lbs. (610 Nm) torque.
G0907034
Install a new O-ring (1), backup ring (2) and O-ring (3) on the head gland. PRINTED IN U.S.A.
