519 Telehandler
HYDRAULIC PUMP
STEP 16
STEP 19
2
2
1
1 2
2 G0907018
G0707008
Remove the brace supporting the oil cooler and install the wheel well (1) using the eight mounting bolts (2).
Install the floor panel (1) using the eight panel mounting bolts (2).
STEP 20
STEP 17
Re-install the battery. Complete Steps 6 through 9 of Section 302 for the correct procedure.
STEP 21 Refill the hydraulic reservoir. 2 1
STEP 22 Start the engine and check for leaks. If no leaks appear, continue to run the engine and test the steering and hydraulic functions for operation. Shut off the engine and check the hydraulic reservoir level. Add fluid if necessary.
2 G0607023
Re-install the battery tray (1) using the four mounting bolts (2).
STEP 18
G0607024
Remove the cap and plug and re-connect the pressure test hose under the battery tray. 913302
602-4
