519 Telehandler
HYDRAULICS
TILT CYLINDER COUNTERBALANCE VALVE QUICK TEST
STEP 25 Watch the pressure gauge as the attachment mount is slowly tilted down. The pressure gauge should read 3350 psi (230 bar) when the attachment mount reaches the full downward position.
STEP 23
If the pressure is less than 3350 psi (230 bar), proceed to the next step.
G1107004
Install a 5000 psi (350 bar) pressure gauge and hose on the battery tray test port. WARNING: The hose must be long enough to observe the pressure gauge from inside the cab or standing clear of the forklift.
STEP 24
G1107011
Start the engine and run at high idle. Tilt the attachment mount up until the tilt cylinder reaches the end of its stroke and hold the joystick in the TILT UP position. The pressure gauge should read 3350 psi (230 bar). If the pressure is less than 3350 psi (230 bar) go to Step 27 of the Tilt Cylinder Direct Test. If the pressure is 3350 psi (230 bar), proceed to the next step.
913302
601-20
