519 Telehandler
REAR AXLE
REAR AXLE INSTALLATION
STEP 3
STEP 1
G1107085
G0807034
Raise the axle into the frame. Be sure all four alignment bushings fit into the boxes in the frame.
STEP 2
G1107086
Remove the caps and plugs from the hydraulic fittings and connect the steering hoses to the top of the axle.
STEP 4 G0807035
Reinstall each wheel onto the axle.
STEP 5
G0807036
Install the four mounting bolts and nuts. Tighten the bolts to 450 ft.-lb. (607 Nm) torque.
G0605021
Install the wheel nuts on the wheel bolts and hand tighten. 913302
