BMA Shield PMC-R Operating Manual
Canopy tip down. 6. Once the shields position is rectified PSA can be switched back on if the roof conditions are satisfactory by pressing the
key.
MM MinCmpAng If a shield has a MM MinCmpAng error then the Compensation cylinder will be close to its minimum retraction. To clear the error in the shield either the legs must be lowered or the canopy tipped down. 1. Disable PSA in the shield where the compensation cylinder STOP has occured.
2. Press the
key if required and check that the LED on this key is OFF.
1. Select direction by using
or
2. While the SCU is in ‘Master Mode’ the function required on the adjacent shield can be selected. The function will stop when the key is released (a Deadman function). 3. Use either of the following keys to increase the caving – canopy angle.
Legs lower.
Canopy tip up. 7. Once the shields position is rectified PSA can be switched back on if the roof conditions are satisfactory by pressing the
EM027362-01
key.
Page 69 of 74
