BMA Shield PMC-R Operating Manual
Initiate an auto TCC adjacent group WARNING Mine safety procedures in regards to shield movement MUST be observed.
1.
Press
2.
To select the neighbour group of shields you want the function to operate, push or
to select the TCC operation in Batch group.
.
The PMCR display will now show: Operating Mode
TCC: SEQU r2 3.
Using the SEQ & RAND).
Direction
34
c100 s100
<
30
SA-Idle
key, the operator can toggle between the operating modes (STAG,
STAG = TCC’s will operate in the Stagger Sequence. (See TCC Stagger section) SEQU = TCC’s will operate in sequence across the selected shields in the direction specified. (See TCC Sequential section) RAND = TCC’s will operate randomly across the selected shields. (See TCC Random section)
3.
Using the key, the operator can toggle between the directions that the group function will operate.
1.
Press the
key to begin the TCC batch operation.
Press the key to stop the TCC group at anytime. This will stop all automatic functions on the face. Press the key and then to stop TCC’s in individual shields without stopping automatic functions in other shields.
EM027362-01
Page 54 of 74
