BMA Shield PMC-R Operating Manual
Initiate a rear AFC advance adjacent group WARNING Mine safety procedures in regards to shield movement MUST be observed.
1.
Press
2.
Select which side you want the function to operate by pressing either
or
RCP: SNAKE 54 < r2 c100 s100 SA-Idle The PMC-R display shows that the Rear Bank Pull will start at Shield 35 and move in the direction of Shield 54.
3.
Pressing
, the operator can toggle between the operating modes (ALL, SNAKE).
All =all Shields will attempt to RCP until they reach their target stroke. Snake = The Rear AFC will pull to form a snake.
4.
Pressing will operate.
, the operator can toggle between the directions that the group function
NOTICE The default direction assumes that when snake mode is selected the operator wishes to bring the snake towards him.
5.
Press
to begin the Rear AFC advance.
The Shields will pull the Rear AFC in the group range to the target stroke. Press
EM027362-01
to stop the Rear Conveyor Pull anytime.
