BMA Shield PMC-R Operating Manual
Initiate a lock on push WARNING Mine safety procedures in regards to shield movement MUST be observed.
If a lock on push is initiated in a Shield the DA ram will push the AFC until the ram stroke meets the target ‘BP LockOnP. Ext’ or until the ‘BP LockOnP.tmo’ timer expires.
1.
Press
BP LockOnPush r2
c100 s100
OFF ON SA-Idle
The default display will prompt the operator to activate the lock on push.
2.
Press
to activate the lock on push.
Press
to stop the Lock on push at anytime.
NOTICE During a lock on push all ram stroke protection is disabled. Use of lock on push can result in damage to the equipment
EM027362-01
Page 44 of 74
