Other Draining Oil from Hydraulic Oil Tank ・ Keep away from fire. ・ Be sure to stop the engine before beginning work. Warning ・ The temperature of the hydraulic oil is high immediately after stopping the engine. Wait until the hydraulic oil temperature has decreased (to 40 ℃ or less) before beginning work.
Items to prepare • Wrenches (17 mm, 19 mm, 36 mm) • Feed pump (power source for feed pump) • Extension cable • Waste oil tank
IN
TE
RN
[1] Press the air breather button (1) on top of the hydraulic oil tank to bleed off the pressure in the tank.
AL
• Waste oil can • Rag • Cleaning fluid
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
[2] Use a wrench (17 mm) to remove the 4 bolts (2), and then remove the feed port cover (3).
RSM-13-19-001E
1
Air breather button
2
Bolt
3
Cover
475 2
