Hydraulic Equipment-related Parts Return Filter Caution
・ Be careful to keep dirt, water, sand, and all other foreign matter out of the tank. ・ When replacing the hydraulic oil, always replace with new oil.
Items to prepare • Wrench (17 mm) • Rag • Cleaning fluid
RN
AL
[1] Press the air breather button (1) on top of the hydraulic oil tank to release the pressure inside the tank.
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
[2] Use a wrench (17 mm) to remove the 4 bolts (2), and then remove the cover (3). • There is a spring inside the cover, so restrain the spring by hand and remove the cover.
RSM-13-18-001E
1
Air breather button
2
Bolt
3
Cover
471 4
