Procedures for Removal and Installation of Cab Inner and Outer Parts Removal and Installation of Cab Front Glass Caution
Reinforced glass is used for the front window. Be extremely careful not to damage it when touching it during removal or installation.
Items to prepare • Wrench (10 mm) • Rag • Cleaning fluid
RN
AL
[1] Use a wrench (10 mm) to remove the 2 bolts (1) each, and then remove the brackets (2) and (3).
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
[2] Remove the covers (4) and (5) for the bracket.
RSM-13-17-001E
1 2 3 4 5
Bolt Bracket Bracket Cover Cover
463 20
