Procedures for Removal and Installation of Cab Inner and Outer Parts Removal and Installation of Wiper Controller Items to prepare • Wrench (10 mm) • Box wrenches (10 mm, 13 mm) • Phillips screwdriver • Flathead screwdriver
1. Removal of Wiper Controller
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
RN
[2] Lift the side upper trim (1), remove the connectors (3), and then remove the side upper trim. Some models have no connector.
AL
[1] Use the Phillips screwdriver to remove the 2 installation screws (2) for the side upper trim (1).
[3] Use a box wrench (13 mm) to remove the 2 turn clips (4) and the 4 bolts (5), and then remove the side rear cover (6).
RSM-13-17-001E
1
Side upper trim
2
Screw
3
Connector
4
Turn clip
5
Bolt
6
Side rear cover
455 12
