Procedures for Removal and Installation of Cab Inner and Outer Parts Removal and Installation of Operator's Seat Items to prepare • Wrench (13 mm)
1. Removal of Operator's Seat
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
RN
[3] Pull the slide lever (1) to slide the seat forward, and then pull the reclining lever (4) to fold the seatback forward.
AL
[1] Pull the slide lever (1) to slide the seat (2) to the rear. [2] Use a wrench (13 mm) to remove the 2 bolts (3) from the front of the seat.
[4] Use a wrench (13 mm) to remove the 2 bolts (5) from the rear of the seat.
452
1
Slide lever
2
Seat
3
Bolt
4
Reclining lever
5
Bolt
RSM-13-17-001E 9
