Procedures for Removal and Installation of Cab Inner and Outer Parts Procedures for Removal and Installation of Cab Inner and Outer Parts
SH200-5
Procedures for Removal and Installation of Cab Inner and Outer Parts Removal and Installation of Cab Assembly ・ Be sure to stop the engine before beginning work. Caution ・ Be sure to inspect the wire rope and other lifting equipment before beginning work. ・ Do not stand or pass under the suspended load.
Items to prepare • Wrenches (13 mm, 19 mm) • Box wrenches (10 mm, 13 mm, 19 mm) • Eyebolt (M24) x 4 • Chains (wire ropes) (with the required breaking load) • Crane (with the required lifting capacity) • Lubricating oil • Rag • Cleaning fluid • Wood planks, etc.
RN
[1] Remove the operator's seat. (For details, see "Removal and Installation of Operator's Seat".)
AL
1. Removal of Cab Assembly
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
[2] Use a box wrench (10 mm) to remove the 4 bolts (1) and another box wrench (13 mm) to remove the 2 bolts (2), and then remove the rear cover (3).
[3] Use a box wrench (10 mm) to remove the 2 bolts (4), and then remove the air conditioner ducts on both sides (5).
1
444
Bolt
2
Bolt
3
Rear cover
4
Bolt
5
Duct
RSM-13-17-001E 1
