Lights Lights
SH200-5
Lights Removal and Installation of Boom Light Caution ・ Be sure to stop the engine before beginning work.
Items to prepare • Wrench (19 mm) • Rag • Cleaning fluid
RN
AL
[1] Remove the connector (1).
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
[2] Use a wrench (19 mm) to remove the nut (2), spring washer (3), and washer (4), and then remove the boom light (5).
1
442
Connector
2
Nut
3
Spring washer
4
Washer
5
Boom light
RSM-13-16-001E 1
