Attachments Removal and Installation of Arm Cylinder ・ Stop the machine on a level location with good footing. ・ Be sure to stop the engine before beginning work. ・ When working together with others, always be sure to exchange signals and pay adequate attention to safety. Caution ・ Always wear protective devices (protective eyewear and safety shoes, etc.) when working with a hammer. ・ Be sure to inspect the nylon sling and other lifting equipment before beginning work. ・ Do not stand or pass under the suspended load.
Items to prepare • Wrenches (19 mm, 36 mm, 41 mm) • Nylon sling (with the required lifting capacity) • Crane (with the required lifting capacity) • Caps
AL
• Plugs • Hammer • Striking rod
RN
• Grease • Rag • Cleaning fluid
TE
• Crossties • Wire
IN
1. Removal of Arm Cylinder
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
[1] Use a crane and nylon sling (1) to secure the arm cylinder (2).
RSM-13-15-001E
1
Nylon sling
2
Arm cylinder
390 10
