Attachments Removal and Installation of Bucket Cylinder ・ Stop the machine on a level location with good footing. ・ Be sure to stop the engine before beginning work. ・ When working together with others, always be sure to exchange signals and pay adequate attention to safety. Caution ・ Always wear protective devices (protective eyewear and safety shoes, etc.) when working with a hammer. ・ Be sure to inspect the nylon sling and other lifting equipment before beginning work. ・ Do not stand or pass under the suspended load.
Items to prepare • Wrenches (19 mm, 36 mm) • Hammer • Striking rod • Crane (with the required lifting capacity)
AL
• Nylon sling (with the required lifting capacity) • Grease • Rag
RN
• Cleaning fluid • Crossties • Wire
TE
1. Removal of Bucket Cylinder
IN
[1] Remove the bucket. (For details, see "Removal and Installation of Bucket".) [2] Remove the bucket link. (For details, see "Removal and Installation of Bucket".)
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
[3] Bring the arm top in contact with the ground. Retract the bucket cylinder rod.
[4] Tie the cylinder rod with wire (2) so that it cannot come out.
RSM-13-15-001E
1
Arm
2
Wire
386 6
